ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation

ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation

نام تجاری: TORICH
شماره مدل: ASTM A213
مقدار تولیدی: 1Ton
قیمت: 1000-1300 USD/Ton
شرایط پرداخت: L/C,D/A,D/P,T/T,Western Union,MoneyGram
توانایی عرضه: 60000 Ton/Tons per Year
اطلاعات دقیق
Place of Origin:
Zhejiang/China
گواهی:
ISO9001 ISO 14001 TS16949
گواهی:
ISO,SGS,Other,ROHS
Steel grade:
300 Series,200 Series,400 series,TP316,200/300 series
Application:
Insulation
Type:
Welded,Seamless,seamless and welded,round
Standard:
GB,ASTM,DIN,AISI,JIS
Thickness:
0.4-30mm,0.25-2.5mm,1mm-40mm,0.2-0.25,0.2mm
Outer diameter:
6mm-219mm/10mmx10mm,1mm-1500mm,3mm upto 23mm,10*10mm-100*100mm,6-760mm
Length:
1m-12m,6m or as customers' request,30mm or custom,0-12m,2.5-8m
Packaging Details:
In bundles or in wooden boxes.
Supply Ability:
60000 Ton/Tons per Year
توضیحات محصول

ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 0

ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation

Material

ASTM A213 covers seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes. Among these, seamless austenitic stainless steel pipes are widely used due to their excellent corrosion resistance, high-temperature strength, and ductility. The base material is typically an austenitic stainless steel, with popular grades including 304, 304L, 316, and 316L.

The PVC coating on steel pipes serves as a protective layer, enhancing corrosion resistance especially for insulation applications by providing additional barrier protection against moisture, chemicals, and physical damage.

Specification

  • Standard: ASTM A213
  • Type: Seamless Austenitic Stainless Steel Pipe
  • Coating: PVC (Polyvinyl Chloride) coating for corrosion protection and insulation support
  • Dimensions: Available as per ASTM A213 dimension standards for OD and wall thickness
  • Grades: Commonly 304, 304L, 316, and 316L stainless steel
  • Heat Treatment: Solution annealed and cold worked depending on grade and application

Chemical Composition

Element 304 (%) 304L (%) 316 (%) 316L (%)
Carbon (C) 0.08 max 0.03 max 0.08 max 0.03 max
Manganese (Mn) 2.00 max 2.00 max 2.00 max 2.00 max
Silicon (Si) 1.00 max 1.00 max 1.00 max 1.00 max
Phosphorus (P) 0.045 max 0.045 max 0.045 max 0.045 max
Sulfur (S) 0.030 max 0.030 max 0.030 max 0.030 max
Chromium (Cr) 18-20 18-20 16-18 16-18
Nickel (Ni) 8-10 8-12 10-14 10-14
Molybdenum (Mo) 2-3 2-3

Mechanical Properties

Property 304 304L 316 316L
Tensile Strength (MPa) 515 min 485 min 515 min 485 min
Yield Strength (MPa) 205 min 170 min 205 min 170 min
Elongation (%) 40 min 40 min 40 min 40 min
Hardness (HRB) Max 95 Max 95 Max 95 Max 95

Key Features

  • Corrosion Resistance: Austenitic stainless steel composition provides excellent resistance to rust, pitting, and crevice corrosion.
  • Seamless Construction: Provides superior strength and reliability with no weld seams, suitable for high-pressure applications.
  • PVC Coating: Enhances corrosion resistance, protects against external environmental factors, and supports thermal insulation.
  • High Temperature Resistance: Suitable for boiler and heat exchanger applications in high temperature environments.
  • Ductility and Toughness: Maintains strength even in cryogenic and low-temperature applications.
  • Low Maintenance: Extended service life with reduced maintenance needs due to protective coating.

Application

  • Boiler tubes and superheater tubes in power plants
  • Heat exchangers and condensers in chemical processing plants
  • Petroleum refineries
  • HVAC systems with insulation requirements
  • Industrial piping requiring corrosion protection and insulation
  • Structural piping in marine and offshore environments

Equivalent Grades

ASTM A213 Grade ASTM A312 Equivalent EN Standard Equivalent JIS Equivalent
TP304 TP304 1.4301 (AISI 304) SUS304
TP304L TP304L 1.4307 (AISI 304L) SUS304L
TP316 TP316 1.4401 (AISI 316) SUS316
TP316L TP316L 1.4404 (AISI 316L) SUS316L


ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 1

ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 2     ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 3


ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 4     ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 5


ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 6



ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 7

ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation 8

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.


Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.


Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.



·
