61X50 DIN2393 ST52-3 DOM Steel Tube For Hydraulic Telescobic Cylinder

اطلاعات پایه
محل منبع: چین
نام تجاری: Torich
گواهی: ISO 9001 TS 16949
شماره مدل: DIN2393
مقدار حداقل تعداد سفارش: 2 تن
قیمت: negotiation
جزئیات بسته بندی: در بسته ها
زمان تحویل: 30-45 روز
شرایط پرداخت: L/C، T/T
قابلیت ارائه: 5000 تن در سال
اطلاعات تکمیلی
Technique: Cold Drawn Thickness: 1 - 60 mm
Application: Hydraulic Pipe Standard: ASTM
Section shape: Round Alloy or not: Non-alloy
Secondary or not: Non-secondary Outer diameter(round): 30 - 250 mm
Length: according to customers' requests Shape: round
برجسته:

Hydraulic Telescobic Cylinder DOM Steel Tube,ST52-3 DOM Steel Tube,Precision Dom Mechanical Tubing

,

ST52-3 DOM Steel Tube

,

Precision Dom Mechanical Tubing


توضیحات محصول

61X50 DIN2393 ST52-3 DOM steel tubes for hydraulic telescobic cylinder



Quick detail

Material :1020 St52-3 Q345B

Size :

63*52

80*68

98*85

116*103

135*121

154.5*140

175*159.5

197*180

220*202mm

Tolerance of OD: (+1.2/1.8mm)

Tolerance of ID:(0,-0.2mm)

Length :as per your requests.

Straightness ≤0.3/1000mm

oval tube ≤0.1

Tensile resistance ≥640MPa

Yield ≥550Mpa

Elongation ≥12%

Hardness 80-100HRB -20℃ 27J 100% Ultrasonic flaw detection



St52-3 steel plate Chemical analysis

Chemical elements C≤ 16mm max C>16mm max Si
max
Mn max P
max.
S
max.
%,by mass 0.24 0.24 0.55 1.60 0.045 0.045



Feature:

High tolerance

Good surface

High performance on Mechanical properties

Quick delivery time



61X50 DIN2393 ST52-3 DOM Steel Tube For Hydraulic Telescobic Cylinder 0
